Product Details:
|
| Dimension: | 113mm*113mm*44mm | Weight: | 690g |
|---|---|---|---|
| Frequency: | 840MHZ/900MHZ(adjustable) | Power: | 0.1~1W(adjustable) |
| Baud Rate: | 1200~230400bps(adjustable) | Built-in Battery(ground Unit): | 3000mAh（12V 18650 3S Battery） |
| Operation Current: | 300mA | Power Supply: | 12.6V |
| Duration: | 15h | ||
| High Light: | 50km wireless video transmission device,900MHX wireless video transmission device,adjustable wireless data Link OEM |
||
This data transmission device is wirelessly connected to the computer, making it ideal for surveys and mapping. A data signal and two S-BUS signals can be transmitted at the same time.
A key function of this device is to solve the problems of short transmission ranges and poor signal quality of remote control signals and data signals. D04 operates in the 915MHz frequency band and has a maximum communication distance of 30 kilometers.
Features
Flexible layout
Computer can be wirelessly connected to the ground unit
Remote control range is extended
Wirelessly connected to the computer
50km transmission range,0 packet loss
Parameters
Frequency : 902-928MHz(Microhard P900)
Baud rate: 1200-115200(adjustable)
Operation current: 300mA
Operation temperature: -10- +60℃
Power: 0.1w-1w(adjustable)
Power supply (air borne unit): DC7.4 - 12V (2S-3S Li battery)
Casing material: Aluminium alloy
Built-in battery (ground unit) : 12v 18650 3S battery
Color: Silver gray
Weight: 43g
Dimension: 113mm*113mm*44mm
