Product Details:
|
| Overall Dimension: | 95mm*56mm*30mm | Serial Port: | TTL RS232(optional) |
|---|---|---|---|
| Product Name: | V31pro D80 Is Suitable For Long-distance Reconnaissance Drone, Transmitting Stable And High-definition Images With 80km | Product Category: | UAV Radio Link |
| Power Supply Voltage: | DC12-50V 3-12S Battery | Power Supply Current: | 2-2.5A(24V Power Supply) |
| Video Latency: | <300ms | Power Supply Port: | XT30 |
The UAV Radio Link product comes equipped with a 2-4dBi rod antenna, which provides a reliable connection even in areas with weak signals. For those looking for an even stronger connection, an 8-12dBi fiberglass antenna is available as an optional addition. This device is perfect for those who require a reliable connection for their drone, such as photographers and videographers looking to capture stunning aerial footage.
With a video latency of under 300ms, the UAV Radio Link product ensures that there is no lag between the drone's camera and the display, allowing for real-time monitoring of video footage. This device is a must-have for anyone who values accuracy and precision in their work.
Overall, the UAV Radio Link product is a reliable and efficient solution for those looking for a drone wireless video transmitter. Whether you are a photographer, videographer, or simply looking to enjoy the thrill of flying a drone, this product is a great addition to your equipment. With its strong RF power, flexible working frequency, and compact design, the UAV Radio Link product is like the Chevrolet Car Radio of the drone world - reliable and effective for any situation. So, what are you waiting for? Get your hands on the UAV Radio Link product today and experience the best drone connection on the market.
This UAV Radio Link product is perfect for use with GPS RC Drone. It provides a reliable transmission range of up to 80km Grade (air to ground) LOS/point to point. The product also features SBUS *2 and LAN*1 data ports, and has an overall weight of 175g (excluding antennas). It can operate in temperatures ranging from -30℃ to +50℃. This product is a great alternative to the Chevrolet Car Radio and IP Mesh Radio.
| Power Supply Current | 2-2.5A(24V Power Supply) |
| Antenna | 2-4dBi Rod Antenna 8-12dBi Fiberglass Antenna(optional) |
| Transmission Range | V31pro D80：80km Grade(air To Ground) LOS/point To Point |
| Video Latency | <300ms |
| Serial Port | TTL RS232(optional) |
| Overall Dimension | 95mm*56mm*30mm |
| Product Category | UAV Radio Link |
| Overall Weight | 175g(Exclude Antennas) |
| Working Frequency | 800MHz(806-826MHz)1.4GHz(1427.9-1467.9MHz) 1.4G(standard) |
| Video Input/output | LAN Connecting LPC Device/PC |
This table presents the technical parameters of the UAV Radio Link product. The product is suitable for various applications, including Agriculture UAV Drone, FPV Drone Accessories, and Chevrolet Car Radio.
One of the most significant applications of the UAV Radio Link product is in agriculture UAV drones. The product is designed to support car aerial antennas with 2-4dBi Rod Antenna, or 8-12dBi Fiberglass Antenna (optional) for better coverage. This makes it an excellent tool for monitoring crops and livestock, providing real-time video feedback.
Another application of this product is in the industrial sector, where it can be used for remote monitoring and inspection of equipment and infrastructure. The drone wireless video transmitter can be connected to LAN Connecting LPC Device/PC for easy video input/output.
The UAV Radio Link product is also ideal for use in emergency situations, such as search and rescue operations. It can be used to provide live video coverage of disaster areas, helping first responders to assess the situation and plan their response.
With its high-quality features, the UAV Radio Link product is a versatile tool that can be used for a range of scenarios. It comes with packaging details of plastic suitcase+ carton packing, and payment terms of T/T.
The UAV Radio Link product comes with technical support and services to ensure that you have a smooth experience with the product. Our technical support team is available to assist you with any issues or questions that you may have regarding the product. Additionally, we offer a range of services including installation, configuration, and maintenance services to help you get the most out of your UAV Radio Link product. Our team of experts is dedicated to providing you with the highest quality technical support and services to ensure that your UAV Radio Link product operates at its full potential.
Product Packaging:
Shipping Information:
Q: What is the place of origin of the UAV Radio Link product?
A: The UAV Radio Link product is made in China.
Q: What is the brand name of the UAV Radio Link product?
A: The brand name of the UAV Radio Link product is CHINOWING.
Q: What is the minimum order quantity for the UAV Radio Link product?
A: The minimum order quantity for the UAV Radio Link product is 1.
Q: What is the delivery time for the UAV Radio Link product?
A: The delivery time for the UAV Radio Link product is 2-8 working days.
Q: What is the price of the UAV Radio Link product?
A: The price of the UAV Radio Link product is USD$2008.32.
Q: What are the payment terms for the UAV Radio Link product?
A: The payment terms for the UAV Radio Link product are T/T.
Q: What are the packaging details for the UAV Radio Link product?
A: The packaging details for the UAV Radio Link product include a plastic suitcase and carton packing.
Q: What is the supply ability for the UAV Radio Link product?
A: The supply ability for the UAV Radio Link product is 1-10000PCS.
